Installation Safety & Guide
To ensure the longevity of your shading system and the safety of all users, please adhere to the following protocols:
Wind & Weather Precautions
The "Curtain" Rule: Our system is designed for quick retraction. If wind speeds exceed 20 mph, or if you notice the fabric "lofting" significantly, use the roping system to pull the shade back and secure it by tying a rope around it like a curtain immediately.
Never Leave Unattended: Similar to an open awning pay attention to current and future weather conditions. Since the recommended Fabric is breathable if its tied down after setup it can surprisingly handle high winds up to 25 mph well Do not leave the shade fully deployed overnight if winds are expected or while away from the campsite.
Installation Safety
Three-Point Contact: When climbing onto an RV or truck to place the 32 lb frames , always maintain three points of contact with your ladder or vehicle for stability.
The "Shake Test": Once the ratchet system is tightened, give the metal structure a firm shake or pull the attached lines without the shade fabric attached. It should not move or swivel. If there is any "play" or sliding, re-tighten the straps before deploying the shade. The frames generaly will not move with the tension of the tiedowns and ropes Do not over tighten.
Weight Limits: Do not hang heavy items (lights, fans, or gear) from the roping system. The Larger the shaded area consider purchasing a light weight shade fabric. never use tarps or non-breathable fabrics.
Vehicle Protection
Anchor Points: Only attach ratchet hooks to structural components of the vehicle (wheel hub, frame, or designated tow points). Avoid attaching to plastic trim, gutters, or fiberglass components that are not load-bearing. The tires are a perfect place to secure the straps. If you have a leveling system on your vehicle, secure the tiedowns only AFTER you have the vehicle leveled. Pay close attention to this fact as you can cause damage to your roof. Detach the tie-downs before releasing the levelers.
Clearance: Ensure the roping system does not interfere with vehicle doors, slide-outs, or hot exhaust vents.
Vehicle Paint & Surface Protection: While the Hovershade™ system includes protective foam and rubber sleeves to shield your vehicle, it is the operator's responsibility to ensure proper clearance. Every vehicle setup is unique; if you identify high-friction areas, please apply additional padding—such as pads. When tying down the frames, do not over tighten. You can use more tie downs with less pressure if necessary .
LINES, CONNECTIONS, FABRIC,WEATHER
- Shade Fabric: IF You want to purchase your own style shade fabric Please follow our Shade fabric guide.
- We provide Kits with shade fabric included. We use 90% Black HDPE lite weight mesh fabric with grommets and our standard sizes are 20x20' and 20x10'. The Black color does not effect the heat distribution and in many cases the lighter colors produce a bright light diffusion glaze that can be uncomfortable for some
- Select the correct size for your intended coverage. Lay the fabric out before installation to identify the center and sides for a perfectly balanced setup. for best results you can zip tie different size or styles of fabric together
- Inspect Ropes: Quickly check for fraying or significant wear before every use to ensure maximum safety.
- Verify Tension: Confirm all ratchets are locked and the "click" mechanism is fully engaged before deploying the shade.
- Clear the Path: Ensure the area between vehicles is clear of people and pets during the "pull-up" phase.
- Check the Forecast: A quick glance at the weather app can save you from a mid-afternoon scramble. If winds exceed 20-25 mph, retract the shade. With the our recommended setup you can retract and extend the shade on a 40+ foot Rv in seconds. Bunch the retracted shade fabric tie a rope around it or place it under the tie-down straps holding the frames. 100 mph winds will not effect it. No need to dismantle and remove the Frames.
Roof Safety & Mounting
Inspection: if required before climbing, verify the roof is dry, clear of debris, and structurally sound. Always wear non-slip footwear.
- Secure Placement: Lift the 32 lbs Bars onto the roof, Tighten the Hovershade™ straps just enough to prevent the bars from shifting. Avoid over-tightening to protect your vehicle's surface.
- Final Check: Perform a "Shake Test" on the structure after the lines are set, and re-tighten straps only if movement is detected.
